Soil's fractal characteristics and influencing factors of main underlying surface in the source area of Heihe River

doi:10.7522/j.issn.1000-694X.2025.00051

Journal of Desert Research ›› 2025, Vol. 45 ›› Issue (6): 279-288.DOI: 10.7522/j.issn.1000-694X.2025.00051

Soil's fractal characteristics and influencing factors of main underlying surface in the source area of Heihe River

Erlong Diao¹(), Guangchao Cao¹(), Ying Liu², Meiliang Zhao¹

^1.Qinghai Provincial Key Laboratory of Physical Geography and Environmental Process / Key Laboratory of Tibetan Plateau Land Surface and Ecological Consorvation （Ministry of Education），College of Geographical Science，Qinghai Normal University，Xining 810008，China / MOE
^2.Qinghai Agriculture and Animal Husbandry Engineering Consulting Corporation，Xining 810008，China

Received:2024-12-04 Revised:2025-03-17 Online:2025-11-20 Published:2025-11-26
Contact: Guangchao Cao

Abstract

Abstract:

To investigate the fractal characteristics and influencing factors of soil particle size in the primary underlying surface of the Heihe River source area， this study focused on the alpine meadow in that region. Soil particle size from 0 to 40 cm depth， along with various physical and chemical indicators， were measured， and environmental factors at each sampling point were extracted. Principal component analysis and the Mantel test were employed to quantify the influence of each factor on the fractal characteristics of soil particle size. Additionally， a partial least squares path model was utilized to explore the effects of interactions among environmental factors on soil fractal characteristics. The results showed that the particle size distribution of alpine meadow soil could be divided into three scale domains： clay domain， silt domain， and sand domain. The boundaries of these domains were largely consistent with the U.S. standard classifications for clay， silt， and sand. The mean fractal dimension of the silt domain （D_silt） within the 0-40 cm soil layer was 2.33， while that of the sand domain （D_sand） was 2.84. The multifractal dimension parameters， namely D₀ （capacity dimension）， D₁ （information dimension）， and D₂ （association dimension）， exhibit the order D₀> D₁> D₂， indicating a non-uniform distribution of soil particle sizes. Soil particle size is a critical factor influencing the fractal characteristics of soil. Topographic factors play a significant role in vegetation growth and the roughness of soil texture by redistributing water and heat resources， which in turn indirectly impacts the fractal characteristics of soil particle size.

Key words: soil particle size, fractal dimension, alpine meadow, the source area of Heihe River

CLC Number:

S152

Erlong Diao, Guangchao Cao, Ying Liu, Meiliang Zhao. Soil's fractal characteristics and influencing factors of main underlying surface in the source area of Heihe River[J]. Journal of Desert Research, 2025, 45(6): 279-288.

Figures/Tables 6

References 47

[1]	宛倩，王杰，王向涛，等.青藏高原不同草地利用方式对土壤粒径分形特征的影响［J］.生态学报，2022，42（5）：1716-1726.
[2]	安克俭，魏霞，赵恒策，等.长江源区高寒草原和高寒草甸土壤粒径分布特征［J］.应用生态学报，2021，32（2）：433-440.
[3]	Mohammadi M， Shabanpour M， Mohammadi M.H，et al.Characterizing spatial variability of soil textural fractions and fractal parameters derived from particle size distributions［J］.Pedosphere，2019，29（2）：224-234.
[4]	Bartoli F， Philippy R， Doirisse M，et al.Structure and self-similarity in silty and sandy soils：the fractal approach［J］.Journal of Soil Science，1991，42：167-185.
[5]	孙方虎，苗雨青，汪勇，等.长江下游沿江湖泊湿地土壤粒径分形特征与有机碳分布：以菜子湖湿地为例［J］.长江流域资源与环境，2024，33（8）：1728-1740.
[6]	李国旗，赵盼盼，邵文山，等.封育对荒漠草原沙芦草群落土壤粒径分形维数及理化性质的影响［J］.草地学报，2018，26（3）：551-558.
[7]	Tyler S W， Wheatcraft S W.Fractal scaling of soil particle-size distributions：analysis and limitations［J］.Soil Science Society of America Journal，1992，56（2）：362-369.
[8]	杨培岭，罗远培，石元春.用粒径的重量分布表征的土壤分形特征［J］.科学通报，1993，38（20）：1896-1899.
[9]	Prospering N， Perugini D.Particle size distributions of some soils from the Umbria Region （Italy）：fractal analysis and numerical modelling［J］.Geoderma，2008，145（3）：185-195.
[10]	苏敏，丁国栋，高广磊，等.呼伦贝尔沙地樟子松人工林土壤颗粒多重分形特征［J］.干旱区资源与环境，2018，32（11）：129-135.
[11]	Rodríguez-Lado L， Lado M.Relation between soil forming factors and scaling properties of particle size distributions derived from multifractal analysis in topsoils from Galicia （NW Spain）［J］.Geoderma，2017，287：147-156.
[12]	南富森，李宗省，张小平，等.黄河北岸兰州段荒漠-草原过渡带土壤粒径分形特征［J］.地球科学，2023，48（3）：1195-1204.
[13]	杜雅仙，樊瑾，李诗瑶，等.荒漠草原不同植被微斑块土壤粒径分布分形特征与养分的关系［J］.应用生态学报，2019，30（11）：3716-3724.
[14]	Posadas A N D， Daniel G， Bitelli M，et al.Multifractal characterization of soil particle-size distributions［J］.Soil Science Society of America Journal，2001，65（5）：1361-1367.
[15]	王有恒，李丹华，卢国阳，等.祁连山气候变化特征及其对水资源的影响［J］.应用生态学报，2022，33（10）：2805-2812.
[16]	金少红，刘彤，庞晓攀，等.高原鼠兔干扰对青海湖流域高山嵩草草甸植物多样性及地上生物量的影响［J］.草业学报，2017，26（5）：29-39.
[17]	童珊，曹广超，张卓，等.祁连山南坡土壤侵蚀时空变化及迁移特征分析［J］.水土保持研究，2022，29（4）：18-27.
[18]	李晓燕，曹广超，陈宗颜，等.2001-2022年祁连山南坡地表温度时空变化特征及驱动因素［J］.中国沙漠，2024，44（5）：84-94.
[19]	袁杰，曹广超，杨登兴，等.祁连山黑河源区植被NDVI时空变化特征及影响因素分析［J］.生态科学，2021，40（5）：172-182.
[20]	李璇，杨帆，李德成，等.祁连山区土壤砂粒含量剖面分布模式及其影响因素［J］.土壤学报，2017，54（4）：854-863.
[21]	杨红玲，姚博，苏永中，等.北方农牧交错带人工林土壤理化性质分布格局［J］.中国沙漠，2024，44（2）：283-294.
[22]	高雅宁，廖李容，王杰，等.禁牧对黄土高原半干旱草地土壤粒径多重分形特征的影响［J］.水土保持学报，2021，35（6）：310-318.
[23]	王文帆，刘任涛，郭志霞，等.腾格里沙漠东南缘固沙灌丛林土壤理化性质及分形维数［J］.中国沙漠，2021，41（1）：209-218.
[24]	韩敏，高永，贺明辉，等.藏锦鸡儿（Caragana tibetica）灌丛沙堆的形态与沉积物特征［J］. 中国沙漠， 2024， 44（2）： 185-195.
[25]	王平，丁智强，李璐杉，等.滇中主要森林类型土壤团聚体稳定性及其变化机制［J］.水土保持研究，2024，31（5）：232-242.
[26]	Meneveau C， Sreenivasan K R， Kailasnath P，et al.Joint multifractal measures：theory and applications to turbulence［J］.Physical Review A，1990，41（2）：894-913.
[27]	张虔，袁杰，曹广超，等.祁连山南坡不同生态系统土壤粒径分布与分形特征［J］.草原与草坪，2024，44（6）：34-41.
[28]	袁杰，曹生奎，曹广超，等.祁连山南坡不同植被类型土壤粒度特征［J］.水土保持通报，2019，39（2）：76-82.
[29]	童珊.祁连山南坡碳酸盐岩区土壤碳转移特征及影响因素研究［D］.西宁：青海师范大学，2024.
[30]	杜志勇，丛楠.植被与土壤特征对青藏高原不同程度退化草地的响应［J］.生态学报，2024，44（6）：2504-2516.
[31]	李相楹，张维勇，刘峰，等.不同海拔高度下梵净山土壤碳、氮、磷分布特征［J］.水土保持研究，2016，23（3）：19-24.
[32]	柴华，何念鹏.中国土壤容重特征及其对区域碳贮量估算的意义［J］.生态学报，2016，36（13）：3903-3910.
[33]	张豪睿，付刚.藏北高寒草甸根系生物量与碳氮分布格局及关联特征［J］.生态学报，2021，41（9）：3625-3633.
[34]	Hudek C， Stanchi S， D'Amico M，et al.Quantifying the contribution of the root system of alpine vegetation in the soil aggregate stability of moraine［J］.International Soil and Water Conservation Research，2017，5（1）：36-42.
[35]	杨几，肖涛，孙靓，等.植被根系对土体水力学特性影响的现状与定量分析［J］.西北大学学报（自然科学版），2024，54（1）：53-62.
[36]	戴黎聪，柯浔，曹莹芳，等.青藏高原矮嵩草草甸地下和地上生物量分配格局及其与气象因子的关系［J］.生态学报，2019，39（2）：486-493.
[37]	范家伟，朱广宇，上官周平，等.黄土丘陵区刺槐林土壤团聚体稳定性和土壤可蚀性动态变化［J］.水土保持学报，2023，37（3）：19-26.
[38]	安尼瓦尔·买买提，杨元合，郭兆迪，等.新疆天山中段巴音布鲁克高山草地碳含量及其垂直分布［J］.植物生态学报，2006，30（4）：545-552.
[39]	白一茹，汪有科.黄土丘陵区土壤粒径分布单重分形和多重分形特征［J］.农业机械学报，2012，43（5）：43-48.
[40]	王德，傅伯杰，陈利顶，等.不同土地利用类型下土壤粒径分形分析：以黄土丘陵沟壑区为例［J］.生态学报，2007，27（7）：3081-3089.
[41]	郭士维，钟斌，许文年，等.不同土地利用方式下粉壤土粒径分形特征：以鄂西典型小流域下牢溪为例［J］.中国水土保持科学（中英文），2022，20（1）：25-32.
[42]	Li H， Meng Z， Ren X，et al.Characteristics of soil particle sizes and fractal parameters under different plantation types of Populus alba ［J］.Forests，2024，15（4）：632.
[43]	童珊，曹广超，闫欣，等.祁连山南坡2000-2020年植被覆盖时空演变及其驱动因素分析［J］.山地学报，2022，40（4）：491-503.
[44]	付建新，曹广超，郭文炯.1998-2017年祁连山南坡不同海拔、坡度和坡向生长季NDVI变化及其与气象因子的关系［J］.应用生态学报，2020，31（4）：1203-1212.
[45]	杨华庆，朱睿，尹振良，等.2001-2020年黄河流域水源涵养区植被覆盖变化及其对气候变化和人类活动的响应［J］.中国沙漠，2024，44（4）：57-70.
[46]	Tahmoure M， Honarbakhsh A， Afzali S F，et al.Fractal Features of soil particles as an indicator of land degradation under different types of land use at the watershed scale in Southern Iran［J］.Land，2022，11（11）：2093.
[47]	赵明月，赵文武，刘源鑫.不同尺度下土壤粒径分布特征及其影响因子：以黄土丘陵沟壑区为例［J］.生态学报，2015，35（14）：4625-4632.

土层深度/cm	土壤粒径/%			理化性质
土层深度/cm	黏粒	粉粒	砂粒	容重/(g·cm^-3)	土壤含水量/%	全氮/(g·kg^-1)	有机质/(g·kg^-1)
0~10	5.67±0.34^a	51.96±2.32^a	42.36±2.60^a	0.91±0.02^c	33.03±2.40^a	5.11±0.32^a	89.36±6.16^a
10~20	5.48±0.31^a	50.74±2.42^a	43.78±2.70^a	1.05±0.04^b	25.73±1.84^b	4.19±0.31^b	64.91±5.55^b
20~30	5.16±0.31^a	49.57±2.55^a	45.27±2.82^a	1.20±0.03^a	24.23±1.83^b	3.49±0.23^bc	56.66±5.43^bc
30~40	5.25±0.29^a	49.13±2.44^a	45.62±2.67^a	1.25±0.04^a	22.03±1.75^b	3.01±0.19^c	43.22±3.94^c
平均值	5.39±0.16	50.35±1.21	44.26±1.34	1.10±0.02	25.92±1.05	3.95±0.14	63.27±3.06

土层深度/cm	土壤粒径/%			理化性质
土层深度/cm	黏粒	粉粒	砂粒	容重/(g·cm^-3)	土壤含水量/%	全氮/(g·kg^-1)	有机质/(g·kg^-1)
0~10	5.67±0.34^a	51.96±2.32^a	42.36±2.60^a	0.91±0.02^c	33.03±2.40^a	5.11±0.32^a	89.36±6.16^a
10~20	5.48±0.31^a	50.74±2.42^a	43.78±2.70^a	1.05±0.04^b	25.73±1.84^b	4.19±0.31^b	64.91±5.55^b
20~30	5.16±0.31^a	49.57±2.55^a	45.27±2.82^a	1.20±0.03^a	24.23±1.83^b	3.49±0.23^bc	56.66±5.43^bc
30~40	5.25±0.29^a	49.13±2.44^a	45.62±2.67^a	1.25±0.04^a	22.03±1.75^b	3.01±0.19^c	43.22±3.94^c
平均值	5.39±0.16	50.35±1.21	44.26±1.34	1.10±0.02	25.92±1.05	3.95±0.14	63.27±3.06
